LEILI High-Frequency Wall Saw
LEILI High-Frequency Wall Saw
The LEILI High-Frequency Wall Saw is designed for professional reinforced concrete cutting. Available in 22 kW and 25 kW configurations, it features wireless remote control and a rail-guided cutting system for controlled blade movement.
Take on demanding concrete cutting projects with the LEILI High-Frequency Wall Saw from MHE Trading. This wall and wire saw system combines a powerful electric drive with wireless remote operation, allowing operators to control cutting and travel functions remotely.
Choose between two power configurations to suit your project requirements:
- 22 kW: Rated motor current of 27.8 A, with a controller net weight of 16.5 kg.
- 25 kW: Rated motor current of 31 A, with a controller net weight of 16 kg.
Both configurations support single-phase 220 V or three-phase 380 V power at 50 Hz, according to the manufacturer’s specifications. Confirm the required electrical configuration with MHE Trading before ordering.
Key features
- Two power options: Select a 22 kW or 25 kW configuration.
- Wireless remote control: Control machine operation remotely.
- Rail-guided cutting: Supports steady, controlled blade travel.
- Adjustable travel speed: Published travel speed of 0–1.3 m/min.
- Wall and wire saw system: Contact MHE Trading to confirm the attachments required for your application.
Technical specifications
| Specification | 22 kW Version | 25 kW Version |
|---|---|---|
| Maximum power | 22 kW | 25 kW |
| Power source | AC | AC |
| Published supply options | Single-phase 220 V / Three-phase 380 V | Single-phase 220 V / Three-phase 380 V |
| Frequency | 50 Hz | 50 Hz |
| Rated main motor current | 27.8 A | 31 A |
| Recommended blade diameter* | ≤1200 mm | ≤1200 mm |
| Listed installed blade diameter | 860 mm | 860 mm |
| Controller net weight | 16.5 kg | 16 kg |
| Machine head weight** | 35.5 kg | 37.5 kg |
| Control method | Wireless remote | Wireless remote |
| Travel speed | 0–1.3 m/min | 0–1.3 m/min |
Ordering information
Contact MHE Trading for pricing, availability, delivery options and package contents. Please specify your preferred power variant, site power supply and cutting requirements when enquiring.
